otk::Display class Reference

00076   : _display(0),
00077     _xkb(false),
00078     _xkb_event_basep(0),
00079     _shape(false),
00080     _shape_event_basep(0),
00081     _xinerama(false),
00082     _xinerama_event_basep(0),
00083     _mask_list(),
00084     _num_lock_mask(0),
00085     _scroll_lock_mask(0),
00086     _grab_count(0),
00087     _screeninfo_list(0),
00088     _rendercontrol_list(0)
00089 {
00090   int junk;
00091   (void)junk;
00092
00093   display = this;
00094
00095   // Open the X display
00096   if (!(_display = XOpenDisplay(NULL))) {
00097     printf(_("Unable to open connection to the X server. Please set the \n\
00098 DISPLAY environment variable approriately.\n\n"));
00099     ::exit(1);
00100   }
00101   if (fcntl(ConnectionNumber(_display), F_SETFD, 1) == -1) {
00102     printf(_("Couldn't mark display connection as close-on-exec.\n\n"));
00103     ::exit(1);
00104   }
00105   if (!XSupportsLocale())
00106     printf(_("X server does not support locale.\n"));
00107   if (!XSetLocaleModifiers(""))
00108     printf(_("Cannot set locale modifiers for the X server.\n"));
00109
00110   // set our error handler for X errors
00111   XSetErrorHandler(xerrorHandler);
00112
00113   // set the DISPLAY environment variable for any lauched children, to the
00114   // display we're using, so they open in the right place.
00115   putenv(std::string("DISPLAY=") + DisplayString(_display));
00116
00117   // find the availability of X extensions we like to use
00118 #ifdef XKB
00119   _xkb = XkbQueryExtension(_display, &junk, &_xkb_event_basep, &junk, NULL,
00120                            NULL);
00121 #endif
00122
00123 #ifdef SHAPE
00124   _shape = XShapeQueryExtension(_display, &_shape_event_basep, &junk);
00125 #endif
00126
00127 #ifdef XINERAMA
00128   _xinerama = XineramaQueryExtension(_display, &_xinerama_event_basep, &junk);
00129 #endif // XINERAMA
00130
00131   // get lock masks that are defined by the display (not constant)
00132   _modmap = XGetModifierMapping(_display);
00133   assert(_modmap);
00134   if (_modmap && _modmap->max_keypermod > 0) {
00135     const int mask_table[] = {
00136       ShiftMask, LockMask, ControlMask, Mod1Mask,
00137       Mod2Mask, Mod3Mask, Mod4Mask, Mod5Mask
00138     };
00139     const size_t size = (sizeof(mask_table) / sizeof(mask_table[0])) *
00140       _modmap->max_keypermod;
00141     // get the values of the keyboard lock modifiers
00142     // Note: Caps lock is not retrieved the same way as Scroll and Num lock
00143     // since it doesn't need to be.
00144     const KeyCode num_lock = XKeysymToKeycode(_display, XK_Num_Lock);
00145     const KeyCode scroll_lock = XKeysymToKeycode(_display, XK_Scroll_Lock);
00146
00147     for (size_t cnt = 0; cnt < size; ++cnt) {
00148       if (! _modmap->modifiermap[cnt]) continue;
00149
00150       if (num_lock == _modmap->modifiermap[cnt])
00151         _num_lock_mask = mask_table[cnt / _modmap->max_keypermod];
00152       if (scroll_lock == _modmap->modifiermap[cnt])
00153         _scroll_lock_mask = mask_table[cnt / _modmap->max_keypermod];
00154     }
00155   }
00156
00157   _mask_list[0] = 0;
00158   _mask_list[1] = LockMask;
00159   _mask_list[2] = _num_lock_mask;
00160   _mask_list[3] = LockMask | _num_lock_mask;
00161   _mask_list[4] = _scroll_lock_mask;
00162   _mask_list[5] = _scroll_lock_mask | LockMask;
00163   _mask_list[6] = _scroll_lock_mask | _num_lock_mask;
00164   _mask_list[7] = _scroll_lock_mask | LockMask | _num_lock_mask;
00165
00166   // Get information on all the screens which are available, and create their
00167   // RenderControl
00168   _screeninfo_list = new ScreenInfo*[ScreenCount(_display)];
00169   _rendercontrol_list = new RenderControl*[ScreenCount(_display)];
00170   for (int i = 0; i < ScreenCount(_display); ++i) {
00171     _screeninfo_list[i] = new ScreenInfo(i);
00172     _rendercontrol_list[i] = RenderControl::getRenderControl(i);
00173   }
00174 }


Public Methods
	Display ()
	Initializes the class, opens the X display.
	~Display ()
	Destroys the class, closes the X display.
const ScreenInfo *	screenInfo (int snum) const
	Gets information on a specific screen.
const ScreenInfo *	findScreen (Window root) const
	Find a ScreenInfo based on a root window.
const RenderControl *	renderControl (int snum) const
	Gets the RenderControl for a screen.
bool	xkb () const
	Returns if the display has the xkb extension available.
int	xkbEventBase () const
	Returns the xkb extension's event base.
bool	shape () const
	Returns if the display has the shape extension available.
int	shapeEventBase () const
	Returns the shape extension's event base.
bool	xinerama () const
	Returns if the display has the xinerama extension available.
unsigned int	numLockMask () const
unsigned int	scrollLockMask () const
const XModifierKeymap *	modifierMap () const
inline::Display *	operator * () const
bool	ignoreErrors () const
	When true, X errors will be ignored.
void	setIgnoreErrors (bool t)
	Set whether X errors should be ignored. Use with care.
void	grab ()
	Grabs the display.
void	ungrab ()
	Ungrabs the display.
void	grabButton (unsigned int button, unsigned int modifiers, Window grab_window, bool owner_events, unsigned int event_mask, int pointer_mode, int keyboard_mode, Window confine_to, Cursor cursor, bool allow_scroll_lock) const
void	ungrabButton (unsigned int button, unsigned int modifiers, Window grab_window) const
void	grabKey (unsigned int keycode, unsigned int modifiers, Window grab_window, bool owner_events, int pointer_mode, int keyboard_mode, bool allow_scroll_lock) const
void	ungrabKey (unsigned int keycode, unsigned int modifiers, Window grab_window) const
Private Attributes
::Display *	_display
	The X display.
bool	_xkb
	Does the display have the XKB extension?
int	_xkb_event_basep
	Base for events for the XKB extension.
bool	_shape
	Does the display have the Shape extension?
int	_shape_event_basep
	Base for events for the Shape extension.
bool	_xinerama
	Does the display have the Xinerama extension?
int	_xinerama_event_basep
	Base for events for the Xinerama extension.
unsigned int	_mask_list [8]
	A list of all possible combinations of keyboard lock masks.
unsigned int	_num_lock_mask
	The value of the mask for the NumLock modifier.
unsigned int	_scroll_lock_mask
	The value of the mask for the ScrollLock modifier.
XModifierKeymap *	_modmap
	The key codes for the modifier keys.
int	_grab_count
	The number of requested grabs on the display.
bool	_ignore_errors
	When true, X errors will be ignored. Use with care.
ScreenInfo **	_screeninfo_list
	A list of information for all screens on the display.
RenderControl **	_rendercontrol_list
	A list of RenderControl objects, which are used for all graphics on a screen.
