Syndicate file format
(This is the reference for coding libsyndicate)





The libsyndicate project is in no way affiliated with Electronic Arts and/or Bullfrog Entertainment.
Syndicate and Bullfrog are trademarks of Electronic Arts.
Syndicate is © 1993 Electronic Arts.

Contents



1  Introduction

This is a documentation that resume informations that was needed to code the libsyndicate.

Thanks to :

The author of this document is Paul Chavent (valefor at icculus dot org).

The Syndicate version covered by this document is the one for PC.

2  List of files and types

2.1  List of data files

This is a list of files with the type of data. Types of data are defined in section 2.2.

The prefix 'h' could mean Hight resolution. For example there are HPOITNER.DAT and LPOINTER.DAT.

The prefix 'm' could mean menu.

The prefix 'i' could mean intro.


Table 1: Table of files.
FileTypeComment

COL01.DATMapColumnGives the type for each of the 256 tiles
GAME[xx].DATGameThe description of the games
HBLK01.DATMapTileThe 256 base tiles that compund maps
HELE-0.ANISpriteElementThe descriptions of sprite elements
HFNT01.DATFontFIXME : don't know for what is it used ?
HFRA-0.ANISpriteFrameThe descriptions of sprite frames
HPAL01.DATPalette5*palettes for maps
HPAL02.DATPalette
HPAL03.DATPalette
HPAL04.DATPalette
HPAL05.DATPalette
HPALETTE.DATPaletteFIXME
HPOINTER.DATSpriteData2*arrow, pick, target, pointers
HPOINTER.TABSpriteTab
HREQ.DATGameFontFonts used for the game screen
HSPR-0.DATSpriteData2*sprites for maps
HSPR-0.TABSpriteTab
HSTA-0.ANISpriteAnimThe descriptions of sprite anims
INTRO.DATFliAnimation for the introduction
INTRO.XMIMusicMusic for the introduction
ISNDS-0.DATSoundDataFIXME
ISNDS-0.TABSoundTabFIXME
ISNDS-1.DATSoundDataFIXME
ISNDS-1.TABSoundTabFIXME
MAP[xx].DATMapDataMap data (tiles reconstitution)
MBRIEF.DATFli
MBRIEOUT.DATFli
MCONFOUT.DATFli
MCONFUP.DATFli
MCONSCR.DATRaw
MDEBRIEF.DATFli
MDEOUT.DATFli
MENDLOSE.DATFli
MENDWIN.DATFli
MFNT-0.DATSpriteData2*The menu fonts (rle encoded)
MFNT-0.TABSpriteTab
MGAMEWIN.DATFli
MISS[xx].DATMissionDefines the mission objectives etc.
MLOGOS.DATRaw
MLOSA.DATFli
MLOSAOUT.DATFli
MLOSEGAM.DATFli
MMAP.DATFli
MMAPBLK.DATRaw
MMAPOUT.DATFli
MMINLOGO.DATRaw
MMULTI.DATFli
MMULTOUT.DATFli
MOPTION.DATFli
MOPTOUT.DATFli
MRESOUT.DATFli
MRESRCH.DATFli
MSCRENUP.DATFli
MSELECT.DATFli
MSELECT.PALPalettePalette for the menus
MSELOUT.DATFli
MSPR-0.DATSpriteData2*The menu sprites (rle encoded)
MSPR-0.TABSpriteTab
MTITLE.DATFli
SAMPLE.ADAudio/sound
SAMPLE.OPLAudio/sound
SOUND-0.DATSoundData
SOUND-0.TABSoundTab
SOUND-1.DATSoundData
SOUND-1.TABSoundTab
SYNGAME.XMIMusic


2.2  List of data types

This is a list of types.


Table 2: Table of types.
TypeReverseFiles associated

Fli INTRO.DAT INTRO.XMI MBRIEF.DAT MBRIEOUT.DAT MCONFOUT.DAT MCONFUP.DAT MCONSCR.DAT MDEBRIEF.DAT MDEOUT.DAT MENDLOSE.DAT MENDWIN.DAT MGAMEWIN.DAT MLOSA.DAT MLOSAOUT.DAT MLOSEGAM.DAT MMAP.DAT MMAPOUT.DAT MOPTION.DAT MOPTOUT.DAT MRESOUT.DAT MRESRCH.DAT MSCRENUP.DAT MSELECT.DAT MSELOUT.DAT MTITLE.DAT MMULTI.DAT MMULTOUT.DAT
Font100%HFNT01.DAT
Game 50%GAME[xx].DAT
MapColumn100%COL01.DAT
MapData100%MAP[xx].DAT
MapTile100%HBLK01.DAT
Mission100%MISS[xx].DAT
Music SYNGAME.XMI
Palette100%HPAL[xx].DAT HPALETTE.DAT MSELECT.PAL
Raw100%MLOGOS.DAT MMAPBLK.DAT MMINLOGO.DAT
Req 75%HREQ.DAT
SoundData ISNDS-[x].DAT SOUND-[x].DAT
SoundTab ISNDS-[x].TAB SOUND-[x].TAB
SpriteAnim100%HSTA-0.ANI
SpriteFrame100%HFRA-0.ANI
SpriteElement100%HELE-0.ANI
SpriteTab100%HPOINTER.TAB HSPR-0.TAB MFNT-0.TAB MSPR-0.TAB
SpriteData100%HPOINTER.DAT HSPR-0.DAT MFNT-0.DAT MSPR-0.DAT


3  File format

The field are integers only, so we will use the standard int types. We prefix them with le_ if it's coded in little endian, with be_ else. For example, if a field is a 16 bit unsigned integer, coded in little endian we call it le_uint16_t.

We will also use a base type called Block. They will be explained later.

3.1  RNC

The files are compressed with a tool called Pro-Pack from Rob Northen Computing.

There are two main parts

3.1.1  Header

The header is in big endian.

struct Header { be_uint32_t _signature; be_uint32_t _unpacked_lentgh; be_uint32_t _packed_lentgh; be_uint16_t _unpacked_crc; be_uint16_t _packed_crc; be_uint8_t _unknown; be_uint8_t _pack_count; } _header;

The signature is always 0x524E4301 (ie the string "RNC ").

3.1.2  Compressed data

The compressed data should be read as a stream by block of 16 bits (big endian) as in the example on figure 1.


Figure 1: An extract of the bitstream.

At the begining of the stream there are two unknown bits. We can skip them (don't know what there are for now).

Then the compressed data are divided in pack. The number of pack is given by the header field _pack_count.
Each pack begin with three huffman tables1. The structure of a table is :

The first table is a raw table, the second is a distance table and the third is a length table.

Then there is 16 bits that give the chunk count.
A chunk is (see figure 2) :

The raw length is given by the first huffman table and next bits of the stream. The raw length next bytes (aligned on 16 bits) are sent to the output.

The distance is given by the second huffman table and next bits of the stream. The distance is the offset from the current output of the pattern. We have to add 1 to the value given by the table.

The length is given by the third huffman table and next bits of the stream. The length is the length of the pattern to copy to the output. We have to add 2 to the value given by the table.


Figure 2: A chunk

3.2  Palette

The Palette files are : HPAL[xx].DAT, HPALETTE.DAT, MSELECT.PAL.

Their structure is :

struct Palette { struct Color { uint8_t _r; uint8_t _g; uint8_t _b; } _rgb[256]; };

There are 16 colours defined, and the value are between 0 and 63 (ie 7 bits).

For an 8 bits system, we need to scale the values between 0 and 255.

3.3  Font

The Font file is : HFNT01.DAT.

His structure is :

struct Font { struct Table { le_uint16_t _offset; le_uint8_t _width; le_uint8_t _height; le_uint8_t _line_offset; } _tab[128]; le_uint8_t _data[]; };
_offset
is the offset in the _data array,
_width
is the width of the font,
_height
is the height,
_line_offset
is the vertical offset where to draw the font from the top (FIXME : check),
_data
are the data.

The pixel are coded with one bit.

If the width is strictly less than 8, each line is coded as le_uint8_t where each bit represent a pixel.

If the width is greater or equal than 8, each line is coded as le_uint16_t where each bit represent a pixel. So the first pixel is the eightith bit, the last pixel is the seventh.

3.4  Req

FIXME : find a better name for this.

The Req file is : HREQ.DAT.

His structure is :

struct Req { struct Entry { Block840 _lines[_height]; le_uint8_t _spares[16]; } _entries[]; };

These data are fonts. They are 8 width and 16 height. The pixel are packed by line. So we have 16 block of 8 pixels and zero alpha channel.

A block of 8 pixel is 16 bytes. The pixels are coded on 4 bits in little endian.

So they are coded as follow :

struct Block840 { le_uint32_t _bit_0; le_uint32_t _bit_1; le_uint32_t _bit_2; le_uint32_t _bit_3; };

So bit 0 of pixel 0 is the 7th bit of _bit_0 and bit 0 of pixel 32 is the 24th bit of _bit_0.

FIXME : some fields are unknown. Moreover there isn't alpha channel, so should we consider a value as transparent ?

3.5  MapData

The MapData files are : MAP[xx].DAT.

His structure is :

struct MapData { le_uint32_t _nb_i; le_uint32_t _nb_j; le_uint32_t _nb_k; le_uint32_t _offset[_nb_i * _nb_j]; le_uint8_t _tile[??? * _nb_k]; };
_nb_i
is the number of tiles on i,
_nb_j
is the number of tiles on j,
_nb_k
is the number of tiles on k,
_offset
is a table with the offset (from byte 12) of the tiles index,
_tile
are the tiles index packed by stack.

For example, if we want the tile at (i;j;k), it is _tile[_offset[j * _nb_i + i] * _nb_k + k]

The figure 3 illustrate the components of a map.


Figure 3: A map.

3.6  MapColumn

The MapColumn file is : COL01.DAT.

His structure is :

struct MapColumn { le_uint8_t _type[256]; };

This file give the type of each tiles from HBLK01.DAT :

enum ColType { None, SlopeSN, SlopeNS, SlopeEW, SlopeWE, Ground, RoadSideEW, RoadSideWE, RoadSideSN, RoadSideNS, Wall, RoadCurve, HandrailLight, Roof, RoadPedCross, RoadMark, NbTypes };

I think that we can use this file to deduce if a tile is walkable and its color for the minimap.

For example, we could say that a tile is walkable :

if((None < type_k && type_k != HandrailLight && type_k < NbTypes) && (None == type_k+1 || type_k+1 == HandrailLight || type_k+1 == NbTypes)) { tile_k is walkable }

For the minimap it is not linear, it seems to be more complicated than associate a type to a colour.

3.7  MapTile

The MapTile file is : HBLK01.DAT.

His structure is :

struct MapTile { le_uint32_t _offset[256][6]; struct Subtile { Block32 _lines[16] } _subtile[986]; };

A tile is 64 pixels width and 48 pixels height. It is compound of 6 subtiles.

Each subtile is 32 pixels width and 16 pixels height. The pixel are packed by line. So we have 16 block of 32 pixels.

A block of 32 pixel is 20 bytes. The pixels are coded on 5 bits in big-endian : one for the transparency and 4 for the index in the palette :

So they are coded as follow :

struct Block32 { be_uint32_t _alpha; be_uint32_t _bit_0; be_uint32_t _bit_1; be_uint32_t _bit_2; be_uint32_t _bit_3; };

The figure 4 illustrate the components of a map tile.


Figure 4: Tiles, Subtiles and blocks.

3.8  SpriteAnim

The SpriteAnim file is : HSTA-0.ANI.

His structure is :

struct SpriteAnim { le_uin16_t _indexes[]; }

This is an array of frame index. So the first frame of the 5th animation is given by _indexes[5]. Then the others frames are given in the SpriteFrame array.

The figure 5 illustrate the components of an animation.


Figure 5: Components of an animation.

3.9  SpriteFrame

The SpriteFrame file is : HFRA-0.ANI.

His structure is :

struct SpriteFrame { struct Frames { le_uint16_t _first; le_uint8_t _width; le_uint8_t _height; le_uint16_t _flags; le_uint16_t _next; } _frames []; // FIXME : give the number of frames };

This is an array of frame descritpion. A frame has a width, height, some flags and is compound of sprite elements. The index of the first sprite element is _first. This is an index (not an offset) in the Sprite Element tab file (see 3.10). The index of the next frame is given by _next. The frame index automatically loop to the first frame.

The _flags field seems to be 0x0100 when it is the first frame of an animation.

The frame 1450 is the persuadotron in the inventory. Then every 6 index, there is the next weapon.

3.10  SpriteElement

The SpriteElement file is : HELE-0.ANI.

His structure is :

struct SpriteElement { struct Element { le_uint16_t _sprite; le_int16_t _x_offset; le_int16_t _y_offset; le_uint16_t _x_flipped; le_uint16_t _next; } _elements[]; // FIXME : give the number of elements };

The _sprite field give the index (not an offset) in the sprite tab file (see 3.11). The _next is the index of the next element. If it is zero there isn't any more elements. The _x_flipped attribut tells if it is horizontaly flipped.

3.11  SpriteTab

The SpriteTab file are : HPOINTER.TAB, HSPR-0.TAB, MFNT-0.TAB, MSPR-0.TAB.

Their structure is :

struct SpriteTab { struct Entry { le_uint32_t _offset; le_uint8_t _width; le_uint8_t _height; } _entries[]; // FIXME : give the number of entries };

The offset give the number of bytes to skip from the begining of the sprite data file (see 3.12).

FIXME : give the apropriate palette for each file.

3.12  SpriteData

The SpriteData file are : HPOINTER.DAT, HSPR-0.DAT, MFNT-0.DAT, MSPR-0.DAT.

Their structure is :

struct SpriteData { le_uint16_t _nb_sprites; union { Block8 _blocks[]; le_uint8_t _rle[]; } _data; };

The sprite datas are encoded as lines of pixels (structured as block) or as rle datas.

The _nb_sprite field gives the number of sprites. It seems that when it is not zero, the data are encoded as rle (the flag is 0x0053 for MSPR-0.DAT and 0x00CD for MFNT-0.DAT). Else, the datas are encoded as lines of pixels (structured in blocks).

If the pixel are packed by line, each line is one or more block of eight pixels. A block is 5 bytes : one for the transparency and 4 for the index in the palette.

3.13  Mission

The Mission file are : MISSXX.DAT. They contain text and available in 4 language :

english
from 01 to 50
french
from 101 to 150
italian
from 201 to 250
german
from 301 to 350

Each string is separated with an EOL (0x0a). Other separator is the pipe '|' (0x7c).

3.14  Game

The Game file are : GAMEXX.DAT.

Their structure is :

struct GameStruct { le_uint8_t _header[6]; le_uint16_t _offsets[128][128]; le_uint16_t _offset_ref; // (32774) struct Pedestrian _pedestrians[256]; // 0x0:8008 (32776) struct Vehicle _vehicles[64]; // 0x0:DC08 (56328) struct Object _objects[400]; // 0x0:E688 (59016) struct Weapon _weapons[512]; // 0x1:1568 (71016) struct Sfx _sfx[256]; // 0x1:5D68 (89448) struct Scenario _scenarios[2048]; // 0x1:7B68 (97128) le_uint8_t _unkn08[448]; // 0x1:BB68 (113512) struct Mapinfos _mapinfos; // 0x1:BD28 (113960) struct Objectives _objectives[10]; // 0x1:BD36 (113974) le_uint8_t _unkn11[1896]; // 0x1:BD98 (114114) };

The header could be seeds for example (FIXME, not sure).

The _offsets field is an array that represent the tiles of the map (every map are 128x128 tiles). The values plus 32774 give an offset in this file that is the entity placed on this tile. The resulting offset can be 98309 max and only peds, vehicle, objects and weapons can be indexed.
It is used for the minimap in the breifing menu. As a clue, for the first level, there are three red points, that are in the _offsets array. It is also probably (not sure) used for te minimap in the game.
The values for offset are :

The _unkn08 field is an array of 2048 structures of 8 bytes. Perhaps it as something to do with A.I.

The _unkn11 field is an array of 129 structures of 15 bytes.

There are 116010 bytes in all files.

3.14.1  Common structure

The Pedestrian, Vehicle, Object and Weapon have a common header like this :

struct { le_uint16_t _offset_next; le_uint16_t _offset_prev; le_uint16_t _tile_i; le_uint16_t _tile_j; le_uint16_t _tile_k; le_uint8_t _unkn10; le_uint8_t _unkn11; le_uint8_t _unkn12[2]; le_uint16_t _index_base_anim; le_uint16_t _index_current_frame; le_uint16_t _index_current_anim; le_int16_t _health; le_uint16_t _offset_unknown; le_uint8_t _type; le_uint8_t _status; le_uint16_t _orientation; };

The _offset_prev and _offset_next plus 32774 gives the offset in this file of the previous and next entity. This is probably used for drawing the scene. I think that for drawing the scene the pseudo-algo could be :

for (k = 0; k < max_k; k++) for(j = 0; j < 128; j++) for(i = 0; i < 128; i++) draw(tile[j * 128 + i]); if(_offsets[j * 128 + i]._tile_k >> 8 == k) entity = _offsets[j * 128 + i] while(entity) { draw(entity) entity = entity._offset_next }

The _tile_* give the location of the entity on the map along i, j or k. Each tile is a cube of side 256x256x128 (see fig. 3). We can deduce the tile id dividing by 256 (along i and j) or 128 (along k).

The _unkn10 is unknown but contain 0x04 for peds, 0x05 for weapons (FIXME check this).

The _index_base_anim give an index (not an offset) in the file HSTA-0.ANI. It is the base offset for the animation of this ped.

The _index_current_frame give an index (not an offset) in the file HFRA-0.ANI. It is the current frame of the current animation displayed.

The _index_current_anim give an index (not an offset) in the file HSTA-0.ANI. It is the current animation.

The _health give the ressources of the element. For a pedestrian it will be the health, for a weapon, the amo. I'am not sure it's alwas a signed int.

The _offset_unknown added to 32774 give an offset in this file. This seems to be a kind of “dependency” (see section 3.14.2).

The _type give the type of objects :

For example, it allow to display a target or a pickup on the game screen or for the minimap.

The _status may contain informations about the status of the object, or for weapons the “subtype”.

The _orientation give the initial orientation (illustrated on fig. 6) of the element :


Figure 6: Orientation of the ped is given i black (0x20 represent 45 degree). The offset of the animation if the ped doesn't move is given in red. And the offset of the ped if he moves is given in blue.

3.14.2  Pedestrians

The _pedestrians is an array of 256 structures that describe pedestrians. This array is at adress 32776 (0x8008), and each structure is 92 bytes.

struct Pedestrian { // - 00 le_uint16_t _offset_next; le_uint16_t _offset_prev; le_uint16_t _tile_i; le_uint16_t _tile_j; le_uint16_t _tile_k; // - 10 le_uint8_t _unkn10; le_uint8_t _unkn11; le_uint8_t _unkn12; le_uint8_t _unkn13; le_uint16_t _index_base_anim; le_uint16_t _index_current_frame; le_uint16_t _index_current_anim; // - 20 le_int16_t _health; le_uint16_t _offset_last_enemy; le_uint8_t _type; le_uint8_t _status; le_uint16_t _orientation; le_uint8_t _unkn28; // when 01 pedestrian, 02 agent, 04 police, 08 guard : change IA and minimap le_uint8_t _unkn29; // - 30 le_uint16_t _unkn30; le_uint16_t _offset_of_persuader; le_uint16_t _unkn34; le_uint16_t _offset_of_vehicle; le_uint16_t _offset_scenario; // - 40 le_uint16_t _offset_scenario; le_uint16_t _unkn42; le_uint16_t _offset_of_vehicle; le_uint16_t _goto_tile_i; le_uint16_t _goto_tile_j; // - 50 le_uint16_t _goto_tile_k; le_uint8_t _unkn52[6]; le_uint16_t _offset_equipment; // - 60 le_uint16_t _mods_info; le_uint8_t _unkn62[6]; le_uint16_t _offset_cur_weapon; // - 70 le_uint8_t _unkn70; le_uint8_t _adrena_amount; le_uint8_t _adrena_dependency; le_uint8_t _adrena_effect; le_uint8_t _unkn74; le_uint8_t _inteli_amount; le_uint8_t _inteli_dependency; le_uint8_t _inteli_effect; le_uint8_t _unkn78; le_uint8_t _percep_amount; le_uint8_t _percep_dependency; le_uint8_t _percep_effect; le_uint8_t _unkn82; le_uint8_t _unkn83[9]; };

The _unkn10 seems to be 4.

The _health of our agent can be 0x10 maximum. When it is less than zero the ped should die.

The _sub_type is used for minimap for example (colored dots) and can be (FIXME):

The _offset_last_enemy is the offset of the last peds that hurt, or persuade this ped (Not realy sure).

The _offset_equipment + 32774 gives the offset in this file of the first equipment of this ped.

The _mods_info gives the level of the mods. It its a bitfield with two bits for each mods :

msb              lsb
sparebraineyeheartchestarmleg gender

. The gender is 1 for femele and 0 for male.

The _offset_cur_weapon + 32774 gives the offset in this file of the current weapon in use.

The IPA levels seems to have 4 bytes. At least 3 bytes are sure. They are discribed on the picture 7.


Figure 7: Detail of IPA field.

The _offset_scenario + 97128 gives the offset in this file of the first and/or current scenario (there are two fields).

3.14.3  Vehicles

The _vehicles is an array of 64 structures that describe vehicles. This array is at adress 56328 (0xDC08), and each structure is 42 bytes.

struct Vehicle { le_uint16_t _offset_next; le_uint16_t _offset_prev; le_uint16_t _tile_i; le_uint16_t _tile_j; le_uint16_t _tile_k; le_uint8_t _unkn10; le_uint8_t _unkn11; le_uint8_t _unkn12; le_uint8_t _unkn13; le_uint16_t _index_base_anim; le_uint16_t _index_current_frame; le_uint16_t _index_current_anim; le_int16_t _health; le_uint16_t _offset_last_enemy; le_uint8_t _type; le_uint8_t _sub_type; le_uint16_t _orientation; le_uint8_t _offset_of_ped; le_uint8_t _unkn30[13]; };

The _offset_of_ped + 32774 gives the offset in this file of the first ped in this vehicle.

3.14.4  Objects

The _objects is an array of 400 structures that describe objects (trees, doors, windows, etc.). This array is at adress 59016 (0xE688), and each structure is 30 bytes.

struct Object { le_uint16_t _offset_next; le_uint16_t _offset_prev; le_uint16_t _tile_i; le_uint16_t _tile_j; le_uint16_t _tile_k; le_uint8_t _unkn10; le_uint8_t _unkn11; le_uint8_t _unkn12; le_uint8_t _unkn13; le_uint16_t _index_base_anim; le_uint16_t _index_current_frame; le_uint16_t _index_current_anim; le_uint8_t _unkn20[4]; le_uint8_t _type; le_uint8_t _sub_type; le_uint16_t _orientation; };

The _sub_type can be :

3.14.5  Weapons

The _weapons is an array of 512 structures that describe weapons. This array is at adress 71016 (0x11568), and each structure is 36 bytes.

struct Weapon { le_uint16_t _offset_next; le_uint16_t _offset_prev; le_uint16_t _tile_i; le_uint16_t _tile_j; le_uint16_t _tile_k; le_uint8_t _unkn10; le_uint8_t _unkn11; le_uint8_t _unkn12; le_uint8_t _unkn13; le_uint16_t _index_base_anim; le_uint16_t _index_current_frame; le_uint16_t _index_current_anim; le_uint16_t _nb_amos; le_uint16_t _unkn22; le_uint8_t _type; le_uint8_t _sub_type; le_uint16_t _orientation; le_uint16_t _offset_next_inventory; le_uint16_t _offset_prev_inventory; le_uint16_t _offset_owner; le_uint16_t _unkn34; };

The _sub_type can be :

The _nb_amos is the number of amos remaining. If the weapon is empty, it is equal to 0xffff (and the weapon is not selectable). The equipement table ?? give more information about each equipment (nb amo max, range, etc.).

FIXME : is there any info for the picture of the weapon in the inventory ?

3.14.6  Sfx

The _sfx is an array of 256 structures that describe sfx (for the flamer, the gauss gun, etc.). This array is at adress 89448 (0x15D68), and each structure is 30 bytes.

struct Sfx { le_uint16_t _offset_next; le_uint16_t _offset_prev; le_uint16_t _tile_i; le_uint16_t _tile_j; le_uint16_t _tile_k; le_uint16_t _unkn10; le_uint16_t _unkn12; le_uint16_t _index_base_anim; le_uint16_t _index_current_frame; le_uint16_t _index_current_anim; le_uint16_t _unkn20; le_uint16_t _unkn22; le_uint16_t _unkn24; le_uint16_t _unkn26; le_uint16_t _offset_owner; };

3.14.7  Scenarios

The _scenarios is an array of 2048 structures that describe scenarios. This array is at adress 97128 (0x17B68), and each structure is 8 bytes.

struct Scen { le_uint16_t _next; le_uint16_t _offset; le_uint8_t _i_factor; le_uint8_t _j_factor; le_uint8_t _k_factor; le_uint8_t _type; };

The _next field give the offset of the next point from the begining of the structure.

The _offset field plus 32774 give an offset in this file.

The _i_factor, _j_factor and _k_factor fields gives (i,j,k) coordinates.

i = (_i_factor < < 7) | 0x0040 j = (_j_factor < < 7) | 0x0040 k = (_k_factor < < 7) | 0x0000

3.14.8  Mapinfos

The _mapinfos is a structure that describe the map. This is at adress 113960 (0x1BD28), and the structure is 14 bytes.

struct Mapinfos { le_uint16_t _map; le_uint16_t _min_x; le_uint16_t _min_y; le_uint16_t _max_x; le_uint16_t _max_y; le_uint8_t _status; le_uint8_t _unkn11[3]; };

The _map gives the number of the map. For example, if _map is 9 the map we should open is MAP09.DAT.

The _status flag is set to 1 if the mission has been successfully completed.

3.14.9  Objectives

The _objectives is an array of 10 structures that describe the objectives of the mission. This array is at adress 113974 (0x1BD36), and the structure is 14 bytes.

struct Objectives { le_uint16_t _type; le_uint16_t _offset; le_uint16_t _tile_i; le_uint16_t _tile_j; le_uint16_t _tile_k; le_uint8_t _status; le_uint8_t _unkn11[3]; };

The _type field can be : 0x00 ??? ,0x01 persuade, 0x02 assassinate, 0x03 protect, 0x05 equipment aquisition, 0x0a combat sweep (police), 0x0b combat sweep, 0x0d raid and rescue, 0x0e use/destroy vehicle, 0x10 evacuate.

The _offset + 32774 gives the offset in this file of the objective.

If “protect”, the next objective are the goals and their type is zero. The list finish with zero and the offset of the protected item ? FIXME.

The _status flag is set to 1 if the objective has to be completed.

3.15  Fli

The Fli files are : INTRO.DAT, ….

There are some specific informations about Bullfrog fli files at ftp://ftp.mplayerhq.hu/MPlayer/samples/game-formats/magiccarpet-fli/.

A description of fli can be found at :

Other descriptions can be found at :

There are some difference with the original description. The header is :

struct { le_uint32_t _size; le_uint16_t _magic; le_uint16_t _frames; le_uint16_t _width; le_uint16_t _height; };

The _size give the size of the header.

3.16  Raw

The Raw files are : MCONSCR.DAT, MLOGOS.DAT, MMAPBLK.DAT, MMINLOGO.DAT.

These files gives raw pixels.


Table 3: Table of raw files.
FileNb of picturesDimension of each picture

MCONSCR1320x200
MLOGOS4032x32
MMAPBLK5064x44
MMINLOGOS4016x16


4  Matrix of missions, maps, and games

The games from 90 to 99 are used for multiplayer games. The others are the 50th.


Table 4: Matrix of games, missions and maps.
GamesMissionMapPaletteCountry

0101012Western Europe
0202023Far East
0303034Mongolia
0404045Iran
0505051California
0606062Iraq
0707071India
0808084Northeast Territories
0909635Kazakhstan
1010101Eastern Europe
1111112Western Australia
1212123Kanchatka
1313134Mozambique
1414205Peru
1515181Central Europe
1616192Greenland
1717353Alaska
1818384Urals
1919345Northern Territories
2020321Scandinavia
2121392Yukon
2222413Siberia
2323904Rockies
2424705Southern States
2525911Indonesia
2626922Mexico
2727713Zaire
2828724Algeria
2929405New England
3030671Argentine
3131932South Africa
3232603Colorado
3333614Sudan
3434625Mid West
3535431Lybia
3636312Venezuela
3737563Atlantic Accelerator
3838574Arabia
3939585Northwest Territories
4040631Kenya
4141642Mauritania
4242663Newfoundland
4343654New South Wales
4444805Colombia
4545811Nigeria
4646822Brazil
4747503Uruguay
4848514Pacific Rim
4949535Paraguay
5050540China (Palette 0 !!! intresting !)
90 161
91 211
92 021
93 051
94 431
95 671
96 721
97 901
98 941
99 171


5  Menus sequence

The menu sequence is depicted on figure 8.


Figure 8: The succession of the differents menu.

6  Equipement guide


Table 5: Table of equipements.
ItemCostRangeAmmoShot

Persuadetron5000256- (0x0032)-
Pistol0128013 (0x000c)0
Guass Gun5000051203 (0x0002)15000
Shotgun250102412 (0x000b)2
Uzi750179250 (0x0031)2
Mini-Gun100002304500 (0x01f3)10
Laser3500040965 (0x0004)2000
Flamer15005121000 (0x03e7)1
Long Ranger1000614430 (0x001d)2
Scanner5004096- (0x0013)-
Medikit5002561 (0x0001)1
Time Bomb250001000- (0x00c7)-
Access Card1000256- (0x0000)-
Energy Shield8000768200 (0x00c7)15


The _nb_amo max for each weapon is :

7  Agents names

There are 68 agents :

AFSHAR AARNOLD EBAIRD LTBALDWIN BLACK BOYD PLABOYESEN BRAZIER BROWN R BUSH CARR PLACHRISMAS CLINTON COOPER ECORPES TCOX DAWSON EDONKIN TDISKETT DUNNE EDGAR LAEVANS FAIRLEY FAWCETT FLINT LTFLOYD GRIFFITHS YDHARRIS EHASTINGS HERBERT HICKMAN HICKS LAHILL MASJAMES INJEFFERY JOESEPH JOHNSON JOHNSTON ONKJONES SKLEWIS NNLINDSELL LALOCKLEY MARTIN MCENTEE MCLAUGHIN OYMOLYNEUX ITHMUNRO RRMORRIS TMUMFORD NIXON PARKER PRATT LAREID MASRENNIE NRICE RIPLEY ROBERTSON HNROMANO KSEAT SKSEN SHAW INDSIMMONS SNELLING TAYLOR TROWERS WEBLEY IWELLESLEY UXWILD UNRWILLIS

8  Methods and tools

8.1  Cheat codes

NUK THEM
Select any country
ROB A BANK
100 million
TO THE TOP
100 million and select any country
COOPER TEAM
Money and items
WATCH THE CLOCK
Fast research completion
DO IT AGAIN
Press [Ctrl] + C to finish mission
MARKS TEAM
All country are yours
OWN THEM
Select any country

8.2  Hexadecimal editor

An hexa editor is mandatory. Graphical, ones are handfull when you have to explore only one file a time. For an overview of all files, command line tools are better i think. For example, to see the objectives structures :

for i in `ls GAME*.DAT`; do echo $i; od -A x -j 113974 -N 98 -t x1 --width=14 $i; done | more

8.3  Opened files

To see what files are open, we can use :

# strace -e trace=open dosbox -conf dosbox.conf MAIN.EXE &

8.4  Strings

Talk abouts strings.

8.5  Memdumps

I use the Memshot tool because it seems that GAMEXX.DAT files are mapped in memory. So if we use dosbox for running Syndicate, we can inspect the dynamic of data in memory.

For example :

  1. - launch dosbox and enter the level 1
    # dosbox -conf dosbox.conf MAIN.EXE &
  2. - get the pid
    # ps -e
  3. - use Memshot
    ./MemshotFe GAME01.DAT [pid [59020 [4]]] ?> s
  4. - move in the game
  5. - use Memshot
    ?> l

The game reinit if you took the shot at the begining of the level !

9  References

10  TODO

Probably a lot of things here !


1
I like this tutorial (fr) http://tcharles.developpez.com/Huffman/

This document was translated from LATEX by HEVEA.
